Borg Warner SX-R Series
Borg Warner SX-R Turbo
Here you will find a series of sliding bearing turbochargers from Borgwarner with a modern compressor part that can handle a wide power range.
Products
Borg Warner S200 Turbine Housing 0,83
T4 bolt pattern with T3 Twin volute opening
Pre-order now
Size turbo
Bigger turbo = Reduced spool = Increased peak power
Smaller turbo = Increased spool = Decreased peak power
Size Compressor
Larger inducer / exducer = Increased peak power = Can handle more charging pressure = Reduced Spool
Smaller inducer / exducer = Reduced peak power = Handles less charging pressure = Fast spool
Billet Compressor wheel = Lighter = Increased spool = Sometimes different angle of blade for Increased top power.
Size turbine
Larger turbine exducer than compressor inducer = Reduced back pressure = Increased peak power
Smaller turbine exducer than compressor inducer = Increased back pressure = Reduced peak power
Number of turbine blades
More turbine blades = Increased spool = Increased back pressure = Reduced peak power
Fewer turbine blades = Reduced spool = Reduced back pressure = Increased peak power
Exhaust housing size
Larger exhaust = Reduced spool = Power moved up = Increased peak power
Smaller exhaust = Increased spool = Power moved down = Decreased peak power
Engine size
Smaller engine = Less exhaust = Reduced back pressure = Difficult to drive large turbine / compressor
Bigger engine = More exhaust gases = Increased back pressure = Easy to drive large turbine / compressor
