Garrett GBC22-350 0,64 Turbocharger
Garrett
-350hp
Reviews
Help others choose right. Be the first to write a review!
Write a reviewGarrett GBC22-350 0,64 Turbo WG
Club Line is a product engineered for small engine displacements. This includes powersports, personal watercraft, and automobiles. These turbochargers feature internally wastegated turbine housings and journal bearing rotating groups. GBC stands for GARRETT BOOST | CLUB LINE.
- Forged Fully-Machined Compressor Wheel
- Journal Bearing Rotating Group
- Internally wastegated turbine housing
Name: Garrett GBC22-350
Power: 150 –350 hp
Engine displacement: 1.0L - 2.5L
Turbo PN: 896055-5003S
Compressor
Inducer: 44 mm
Exducer: 56 mm
A/R: 0,59
Turbine
Inducer: 50 mm
Exducer: 46 mm
A/R: 0,64
----------------
